Hydraulic Gear Pump OT200
| Item | Specification |
|---|---|
| Pump Type | External Gear Pump |
| Model | OT200 |
| Design | Compact & Durable |
| Performance | Stable Flow Output |
| Efficiency | High Mechanical Efficiency |
| Noise Level | Low Noise Operation |
| Service Life | Long Working Life |
| Customization | OEM & ODM Supported |
| Options | Custom Shaft / Flange / Port |
| Application | Construction & Agricultural Machinery |
Product Information
High-Performance Hydraulic Gear Pump OT200 | Reliable Industrial Gear Pump Supplier & Manufacturer
The OT200 hydraulic gear pump delivers consistent high-pressure performance across heavy-duty industrial applications. Designed for procurement teams that need verified flow rates, tight tolerances, and dependable supply chains, this pump is manufactured under strict quality control with full OEM/ODM flexibility.
Whether you need standard units in volume or a fully customized solution with private-label packaging, our 10+ years of manufacturing experience means shorter lead times and fewer supply disruptions.
Key Features & Buyer Benefits
| Feature | Benefit |
|---|---|
| High volumetric efficiency (≥92%) | Lower energy waste, reduced operating costs per cycle |
| Hardened alloy steel gears | Extended service life under continuous high-pressure loads |
| Precision-machined housing | Minimized internal leakage, stable flow rate output |
| Wide viscosity compatibility | Operates reliably across fluid types and temperature ranges |
| Compact footprint design | Easier integration into existing hydraulic circuits and machinery |
| Low noise operation (≤72 dB) | Meets workplace safety standards without additional dampening |
Why procurement teams choose the OT200:
- Verified batch-to-batch consistency — every unit tested before shipment
- Flexible MOQ for trial orders and long-term contracts
- Direct-from-manufacturer pricing with no intermediary markup
- Full traceability documentation available per shipment
Technical Specifications — OT200 Hydraulic Gear Pump
| Parameter | Specification |
|---|---|
| Model | OT200 |
| Pump Type | External gear pump |
| Displacement | 4.10–30.00 cm³/rev (OT200 series; confirm size code) |
| Rated Pressure | Model-specific; confirm size-dependent continuous limit |
| Peak Pressure | Model-specific; confirm peak duration and limit |
| Rated Speed | Confirm selected size and inlet conditions |
| Max Speed | Size-dependent; confirm full code |
| Theoretical Flow (by selected size) | 6.15–45 L/min @ 1500 rpm; actual flow depends on efficiency |
| Volumetric Efficiency | ≥92% |
| Inlet Port | G1-1/2" (customizable) |
| Outlet Port | G1-1/2" (customizable) |
| Shaft Type | Keyed / Splined (per request) |
| Rotation | CW / CCW (specify at order) |
| Operating Temp | -20°C to +100°C |
| Fluid Compatibility | Mineral oil, synthetic hydraulic fluid |
| Noise Level | ≤72 dB(A) |
| Weight | Confirm selected assembly |
| Mounting | SAE 2-bolt / 4-bolt flange (customizable) |
All specifications subject to confirmation based on your application requirements. Contact us for a detailed performance curve.
OEM & ODM Capabilities — Your Pump, Your Brand
We support hydraulic gear pump manufacturers, system integrators, and distributors who need white-label or fully customized pump solutions without investing in tooling or production lines.
Customization Options
| Customization Area | Available Options |
|---|---|
| Displacement | Modified from 180–220 mL/rev range |
| Port configuration | SAE, BSP, NPT, metric thread |
| Shaft dimensions | Custom diameter, length, spline profile |
| Seal materials | NBR, FKM (Viton), PTFE |
| Surface treatment | Zinc plating, black oxide, powder coating |
| Branding | Your logo, model number, label design |
| Packaging | Neutral box, custom carton, branded pallet wrap |
| Documentation | Custom spec sheets, certificates with your branding |
How the Custom Order Process Works
| Step | Action | Timeline |
|---|---|---|
| 1 | Submit requirements (specs, volume, branding needs) | Day 1 |
| 2 | Engineering review & DFM feedback | 2–3 business days |
| 3 | Quotation with lead time confirmation | 1–2 business days |
| 4 | Sample production & approval | 10–15 business days |
| 5 | Bulk production | 20–35 business days (volume-dependent) |
| 6 | Pre-shipment inspection & documentation | 2–3 business days |
| 7 | Delivery (FOB / CIF / DDP available) | Per Incoterms agreed |
Minimum order: Negotiable based on customization complexity. Trial orders accepted for new partnerships.
Frequently Asked Questions
Q: What is the hydraulic gear pump OT200 price for bulk orders?
A: Pricing depends on order volume, customization level, and shipping terms. We offer tiered pricing — larger quantities unlock better unit costs. Request a quote with your target quantity for an accurate breakdown.
Q: Can you match an existing OT200 pump we're currently sourcing?
A: Yes. Send us the technical drawing or a sample unit. Our engineering team will reverse-engineer and produce a compatible replacement, often at a lower cost with equivalent or better performance.
Q: What quality certifications do your pumps carry?
A: All OT200 pumps are manufactured under ISO 9001:2015 systems and carry CE marking. SGS test reports are available on request. Every unit undergoes 100% pressure and leak testing before shipment.
Q: Do you support white-label and private branding?
A: Absolutely. We provide full white-label service including custom logos on the pump body, branded packaging, and your own model numbers on documentation.
Q: What are your payment and shipping terms?
A: We accept T/T, L/C, and trade assurance payments. Shipping terms include FOB, CIF, and DDP to major ports worldwide. Partial shipments can be arranged for urgent orders.
Q: How do I start a bulk order or OEM project?
A: Click the button below or send us a message with your specifications, target quantity, and delivery timeline. Our sales engineering team responds within 24 hours on business days.
Get Your OT200 Quotation — Fast Response Guaranteed
Ready to secure reliable hydraulic gear pump supply with full customization support?
Send us your requirements today:
- Target specifications or reference model
- Estimated annual volume
- Branding / packaging preferences
- Preferred Incoterms & destination port
